Image Sensor

Model

S1

Sensor

1/1.8” 4.16MP Sony IMX664 STARVIS2 CMOS

Maximum Resolution

2688x1520@60fps

Minimum Illumination

0.005lux @F1.0(Color) / 0.001lux@F1.0 (B/W)

Camera

AGC

Auto/Manual

S/N Ratio

≥50dB（AGC OFF）

Shutter Speed

1/2 - 1/20 ,000s,Slow shutter support

Wide Dynamic Range

Digital WDR

Exposure Mode

Auto/ Manual/shutter mode

AWB

Yes

Day & Night

Day

Compression

Video Compression

H.265/H.264 Main Profile /M-JPEG

Audio Compression

G711U,G711A,PCM

Image Resolution

Main Stream

2688×1520@60fps/2304x1296@90fps/1920×1080@120fps

Sub Stream

800x448/640×480/480x360/352×288@60fps

General Protocol

Network Protocol

TCP/IP/HTTP/NTP/DHCP/SMTP/RTSP/P2P

ONVIF protocol

Yes

P2P

TUYA APP

Support for Tuya APP on Android, IOS(Default without…)

Function

Web Configuration

Yes

OSD

Yes

Motion Detection

Yes

Interface

Wired

1ch 10/100 Base Ethernet,RJ45 interface

UART

Support

Other

Power Supply

DC 12V,voltage range 7.4-26V

Size/Weight

32x30mm+19x19mm /14g

Operation Temperature

-30°C~60°C

Working Humidity

≤90%RH(non-condensing)
