IMA80L15 Mstar 328Q+Sony IMX415
IMA80L15 4K Ultra Low-illumination HD Network Camera Module，With upgraded H.265 encoding technology, Eco-savvy series brings high efficient video compression capability. It can save bandwidth and storage. Embedded Web Server, support Internet Explore
monitoring, configuration, upgrade;Standard SDK(Linux,Windows)，easily to be integrated with other digital systems.
IMA80L15
4K Ultra Low-illumination HD Network Camera Module
Key features：
● 1/2.8” Ultral Low-illumination Progressive Scan CMOS;
● 4K HD resolution;
● Embedded Web Server, support Internet Explore monitoring, configuration, upgrade;
● Support sub domain, easily to implement DHCP (ADSL dial-up);
● Support Danale APP on Android, IOS by P2P;
● Support ONVIF 2.6;
● H.265/H.264 main profile encoding, two simultaneous video streams ;
● Standard SDK(Linux,Windows)，easily to be integrated with other digital systems.
|
Models |
IMA80L15 |
|
|
4K Ultra low-illumination HD Network Camera Module |
||
|
Image Sensor |
1/2.8” 8.0MP CMOS Sony IMX415 sensor |
|
|
Min. Illumination |
Color：0.01Lux |
|
|
S/N Ratio |
≥72dB |
|
|
Digital noise Reduction |
DNR,3DNR |
|
|
Exposure Mode |
Auto/Manual/shutter mode（shutter range variable） |
|
|
White Balance |
Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
|
|
Day & Night |
Day / Night / External control（IR Cut Filter） |
|
|
Video Compression |
H.265/H.264 Main Profile |
|
|
Audio Compression |
G.711/G.711.A |
|
|
Max. Image Resolution |
3840*2160 at 20fps |
|
|
Image Resolution |
Main stream |
3840*2160 at 20fps,3072*2048/2592*1944/2560*1440/2304*1296/2048*1536/1080P/960P/720P at 30fps |
|
Sub-stream |
720*480/D1/VGA/640*360/CIF at 30fps |
|
|
Streams |
Dual streams |
|
|
Bitrate |
CBR/VBR bitrate：50Kbps~12Mbps variable |
|
|
Simultaneous Live View |
Main stream Up to 5,Sub-stream Up to 5 |
|
|
OSD |
Support camera name,time display ,etc,OSD position can be adjusted |
|
|
Motion detect |
Support |
|
|
P2P |
Android,IOS |
|
|
Protocols |
HTTP/NTP/DHCP/UDNP/RTSP/P2P/ONVIF |
|
|
Onvif |
Onvif 2.6 |
|
|
Network |
10/100M Base-TX Ethernet, RJ45 Connector |
|
|
Store |
Unspport |
|
|
Protection Level |
TVS 6,000V lightning protection |
|
|
Power Supply |
12VDC/POE |
|
|
Dimensions |
38x38mm |
|
|
Working Temperature |
-30°C ~85°C, Humidity≤90%RH(Unsupport-condensing) |
|
