EC-IP4050U
EC-IP4050U 4MP IP White Light Underwater POE Camera using stainless steel 316L, Support POE, IP68 Protection Level, Support multiple network monitoring: Web viewer, CMS,Max. water depth: 50m, it can be widely used in swimming pools, aquaculture, oceans and other underwater monitoring scenes.
EC-IP4050U
4MP IP White Light Underwater POE
Key Features：
● 1/3” 4MP CMOS Sensor● 2560×1440@25fps
● IP68, POE – Max. water depth: 50m
● Multiple network monitoring: Web viewer, CMS; ● White light Distance: 15m ● Housing material: stainless steel 316 ● Attachment bar: adjustable by 180° ● Toughened safety glass (ESG)
|
EC-IP4050U |
|
|
Image sensor |
|
|
Sensor |
1/3" CMOS |
|
Effective pixels |
2560x1440 |
|
Minimum illumination |
Color 0.6Lux/F1.4 |
|
Camera |
|
|
Light distance |
15m |
|
Electronic shutter |
1/50(1/60)s-1/100,000s |
|
Lens |
Focus f=2.8-12mm |
|
Lens mount |
M12 |
|
Image resolution |
|
|
Main stream |
2560x1440@25fps |
|
Sub stream |
704*576@15fps |
|
General protocol |
|
|
Protocol |
HTTP/Onvif/DHCP/DDNS/NTP |
|
Interface |
|
|
Wired |
10Base-T/100Base-TX |
|
Network protocol |
RJ45 |
|
Other |
|
|
Power supply |
Dual POE |
|
Size |
Ø 158 x 144mm |
|
Operation temperature |
-10°C- +60°C |
|
Material |
Stainless steel 316L |
|
Cable |
CAT6 |
|
Net weight |
N.W.2.6kg +cable 0.12kg/m |
-
