KD8501

Image sensor

Screen size

5MP, 1/2.7'', Day/Night

Maximum Resolution

2592x1944@30fps

Minimum illumination

Color：0.05Lux B/W：0.01Lux

Video parameters

Resolution

Mainstream: 2560x1440/1920x1080/@30fps

Sub stream: 640x480/640x360@30fps

FOV

Horizontal: 125°Vertical: 65°

WDR

DWDR

Supplement light

IR light,940nm

Video compression standard

H.265/H.264

Audio parameters

Audio input

1 built-in omnidirectional microphone

Audio compression standard

G711U

Audio output

1 built-in loudspeaker

Audio quality

noise suppression and echo cancellation

Volume adjustment

Adjustable

Network parameters

Network protocol

HTTP,TCP/IP,IPv4,DHCP,NTP,SIP

Wi-Fi

Support, 2.4G

Device interfaces

Alarm input

2

Network interface

1 RJ-45, 10/100 Mbps self-adaptive

Exit button

1

RS-485

2

TF card

Reserved

General

Button

1 physical button

Installation

Surface mounting

Protective level

IP65

Working temperature

-30 °C to 70 °C

Working humidity

10% to 95% (no-condensing)

Dimension (W × H × D)

139mm ×55mm ×31.5mm

Application environment

Outdoor and indoor
