EC-IP8060U
EC-IP8060U 5MP IP Underwater White light Varifocal POE IP Camera(Deepwater) using stainless steel 316L, Support POE, IP68 Protection Level, Support multiple network monitoring: Web viewer, CMS,Max. water depth: 60m, it can be widely used in swimming pools, aquaculture, oceans and other underwater monitoring scenes.
EC-IP8060U
5MP IP Underwater White Light Varifocal POE Camera
Key Features：
● 1/2.7” 5MP CMOS Sensor● 2592×1944@15fps
● Support Onvif
● Focus f=2.8-12mm automatic zoom lens
● White light Distance: 30m ( ir leds optional)
● Underwater depth 60m Max
● IP68, POE
|
EC-IP8060U |
|
|
Image sensor |
|
|
Sensor |
1/2.7" CMOS |
|
Effective pixels |
2592x1944 |
|
Minimum illumination |
Color 0.1Lux/F1.4 |
|
Camera |
|
|
Light distance |
30m |
|
Electronic Shutter |
1/50(1/60)s-1/100,000s |
|
Lens |
Focus f=2.8-12mm |
|
Lens mount |
M12 |
|
Image resolution |
|
|
Main Stream |
2592x1944@15fps |
|
Sub Stream |
704*576@25fps |
|
General protocol |
|
|
Protocol |
HTTP/Onvif/DHCP/DDNS/NTP |
|
Interface |
|
|
Wired |
10Base-T/100Base-TX |
|
Network Protocol |
RJ45 |
|
Other |
|
|
Power supply |
POE IEEE802.3at/af |
|
Size |
370 x 140 x170mm |
|
Operation temperature |
-10°C- +60°C |
|
Material |
Stainless steel 316L |
|
Cable |
CAT6 |
|
Net Weight |
N.W.13kg +cable 0.12kg/m |
-
