Model | EC-HW8018BL |
Camera type | 8MP HD Waterproof IR camera |
Image Sensor | Sony IMX415 sensor |
Effective Pixels | PAL:3840x2160@25fps NTSC:3840x2160@30fps |
Resolution |
3840x2160 |
IR-LED | 24pcs mini Array IR Leds |
Illuminate Distance | 40m IR Distance |
Day/Night | IR-CUT filter |
Min.Illumination | Color 0.01Lux |
Electronic Shutter | 4/25-1/45,000s |
Lens | 6mm Lens |
Lens Mount | M12 |
Video output | 1CH AHD/TVI/CVI/CVBS Video output |
Work environment | -10℃~60℃90%RH |
Power supply | DC 12V±10% |
BLC | Auto BLC |
White Balance | Auto White Balance |
Max transmission distance | common 75-3 lines can be up to 500 m |
Waterproof Criterion | IP66 |
Package Size | 27 x 18 x 16 cm |
Gross weight | 0.67 Kg |
